Description
The MOOER RADAR is a full-featured professional speaker simulator and impulse response convolver. Not only does it carry 30 speaker cabinet models but it also has optional microphone and power amp simulation. Ideal for recording or hooked up to your favourite headphones for practice. Load fine acoustic impulse responses into the RADAR to turn your solid body electric into a shimmering Stradivari or load your favorite speaker cabinet to turn a buzzy little distortion into a stadium rocking sound!
Main Features
30 different speaker cab models
11 mic models
4 power amp models
Customizable EQ stage
Capable of loading custom IRS
Store and recall up to 36?user presets
Connect to PC editor via USB
Supports headphones and lineout
MOOER STUDIO EDITOR
Download the MOOER STUDIO software from our Downloads & Firmware page on the MOOERAUDIO website.
http://www.mooeraudio.com/?FirmwareUpdate.html
After installation, connect your device to the computer using a USB cable
Open the MOOER STUDIO software and select Search Device
Select your device from the drop-down menu
Select Open Device
FIRMWARE UPDATE
Connect your RADAR to the computer using a USB cable
Press and hold the MENU and power on the RADAR. This will boot RADAR into Update Mode
Open the MOOER STUDIO software. Press the Search Device button and then select RADAR UPDATE from the Device drop down menu
Press the Update button and wait for the update to complete
Specifications
Input: 1/4 mono audio jack.(Impedance: 100k ?)
Output: 1/4 mono audio jack (Impedance: 470 ?)
1/8 stereo audio jack (Impedance: 10 ?)
Sampling rate: 44.1K
Sampling accuracy:24bit
Signal to noise ratio:100dB
Frequency Range:20Hz~20KHz
Power requirements: 12V DC Only use the power supply provided
Current Draw:300mA
Dimensions:93.5mm(D) x 42mm(W) x 52mm(H)
Weight:150g
